Uses : For Air,Water,Hydraulic,
Lubrication,Fuel dispensing etc.

Design & Structure

  • Heavy duty steel construction & Protect pipe for reel drum.
  • All bolted assembly without welding
  • Dual frame ,guide plate & ball bearing support.
  • Special heat-treatment spring & non-corrosive ratchet.
  • 4-way roller assembly.
  • Full flow shaft and swivel.
  • Standard inlet 90° balanced pressure swivel joint (NBR Packing)
  • All(Outlet & inlet) connection threads are female NPT(Other threads can be furnished when you request)
  • All materials are carbon steel as standard(Stainless, Aluminum and other materials are available when you request)

Painting : powder coat.

HOSE

  • Low pressure hose reels are furnished standard with PVC.
  • Medium pressure hose reels are furnished standard with S.A.E 100R1 TYPE AT one wire braid hose.
  • High pressure hose reels are furnished standard with S.A.E 100R2 TYPE AT two wire braid hose.

Other specifications are available

Specification

Specification
Available Hose specifications Max Pressure Max Temperature Rewind Type Installation
Size(Inch) Hose Material Length(MR)
1/4inch~1-1/2inch PVC(1T/B) 20MR~30MR 2900psi/200bar 212℉ (100℃) Spring Floor, Wall
Rubber(1W/B) 70ft~100ft
Hose Reel | Spring Rewind
크게보기
Specification
MODEL NO. HOSE CAPACITY REEL DIMENSIONS
I.D O.D LEN GTH A B C D E F G H X Y
mm
inch		 mm
inch		 meter
feet		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch		 mm
inch
SD13-3 12.7
1/2		 20.6
0.8		 20
70		 260
10.2		 120
4.7		 200
7.9		 395
15.6		 450
17.7		 370
14.6		 490
19.3		 265
10.4		 220
8.7		 280
11
SD13-4 12.7
1/2		 20.6
0.8		 25
80		 260
10.2		 120
4.7		 200
7.9		 395
15.6		 450
17.7		 370
14.6		 490
19.3		 265
10.4		 220
8.7		 280
11
SD13-5 12.7
1/2		 20.6
0.8		 30
100		 290
11.4		 150
5.9		 200
7.9		 395
15.6		 450
17.7		 400
15.7		 490
19.3		 265
10.4		 250
9.8		 280
11
SD19-2 19
3/4		 27.8
1.09		 15
50		 290
11.4		 150
5.9		 250
9.8		 395
15.6		 450
17.7		 410
16.1		 490
19.3		 265
10.4		 250
9.8		 280
11
SD19-3 19
3/4		 27.8
1.09		 20
70		 350
13.8		 210
8.3		 250
9.8		 395
15.6		 450
17.7		 470
18.5		 490
19.3		 265
10.4		 310
12.2		 280
11
SD19-4 19
3/4		 27.8
1.09		 25
80		 350
13.8		 210
8.3		 250
9.8		 440
17.3		 500
19.7		 470
18.5		 545
21.5		 290
11.4		 310
12.2		 310
12.2
SD19-5 19
3/4		 27.8
1.09		 30
100		 380
15		 240
9.4		 250
9.8		 440
17.3		 500
19.7		 500
19.7		 545
21.5		 290
11.4		 340
13.4		 310
12.2
SD25-2 25
1		 35.6
1.4		 15
50		 320
12.6		 180
7.1		 250
9.8		 440
17.3		 500
19.7		 450
17.7		 545
21.5		 290
11.4		 280
11		 310
12.2
SD25-3 25
1		 35.6
1.4		 20
70		 380
15		 240
9.4		 250
9.8		 440
17.3		 500
19.7		 510
20.1		 545
21.5		 290
11.4		 340
13.4		 310
12.2
SD25-4 25
1		 35.6
1.4		 25
80		 350
13.8		 210
8.3		 250
9.8		 500
119.7		 550
19.7		 480
18.9		 590
23.2		 315
12.4		 310
12.2		 350
13.8
SD25-5 25
1		 35.6
1.4		 30
100		 380
15		 240
9.4		 250
9.8		 500
19.7		 550
19.7		 510
20.1		 590
23.2		 315
12.4		 340
13.4		 350
13.8
SD32-1 32
1-1/4		 43
1.7		 10
30		 270
10.6		 150
5.9		 260
10.2		 500
19.7		 600
23.6		 400
15.7		 660
26		 360
14.2		 325
12.8		 350
13.8
SD32-2 32
1-1/4		 43
1.7		 15
50		 320
12.6		 180
7.1		 260
10.2		 500
19.7		 600
23.6		 450
17.7		 660
26		 360
14.2		 325
12.8		 350
13.8
SD32-3 32
1-1/4		 43
1.7		 20
70		 370
14.6		 230
9.1		 260
10.2		 500
19.7		 600
23.6		 500
19.7		 660
26		 360
14.2		 325
12.8		 350
13.8
SD40-1 40
1-1/2		 50.6
2		 10
30		 320
12.6		 180
7.1		 260
10.2		 500
19.7		 600
23.6		 450
17.7		 660
26		 360
14.2		 325
12.8		 350
13.8
SD40-2 40
1-1/2		 50.6
2		 15
50		 370
14.6		 230
9.1		 260
10.2		 500
19.7		 600
23.6		 500
19.7		 660
26		 360
14.2		 325
12.8		 350
13.8
SD40-3 40
1-1/2		 50.6
2		 20
70		 420
16.5		 280
11		 260
10.2		 500
19.7		 640
25.2		 550
21.7		 700
27.6		 380
15		 375
12.8		 350
13.8

※The specifications are subject to change without notice for improvement.
